W-71 and W-77 Pneumatic Spray Guns for Latex and Standard Paints
W-71 and W-77 Pneumatic Spray Guns for Latex and Standard Paints — view 1 W-71 and W-77 Pneumatic Spray Guns for Latex and Standard Paints — view 2 W-71 and W-77 Pneumatic Spray Guns for Latex and Standard Paints — view 3 W-71 and W-77 Pneumatic Spray Guns for Latex and Standard Paints — view 4 W-71 and W-77 Pneumatic Spray Guns for Latex and Standard Paints — view 5 W-71 and W-77 Pneumatic Spray Guns for Latex and Standard Paints — view 6 W-71 and W-77 Pneumatic Spray Guns for Latex and Standard Paints — view 7 W-71 and W-77 Pneumatic Spray Guns for Latex and Standard Paints — view 8 W-71 and W-77 Pneumatic Spray Guns for Latex and Standard Paints — view 9

Manual spray guns

W-71

W-71 and W-77 Pneumatic Spray Guns for Latex and Standard Paints

Manufacturer
Fulian
Model
W-71
Ordering
Online order or bulk inquiry

ORDER EQUIPMENT

Choose your configuration.

Product amount Select a configuration

Shipping and taxes to be confirmed before payment. Availability is unconfirmed. Submitting an order does not collect payment.

Request a bulk quote ↗

Confirm coating compatibility and the exact configuration before ordering.

TECHNICAL INFORMATION

Product details.

Review the current supplier-listed configuration and confirm the package, coating compatibility and operating requirements before ordering.

FULIAN W-71 Specifications

Model Feed Type Fluid Nozzle Orifice (mm) Air Pressure MPa (bar) Air Consumption (ml/min) Fluid Output (ml/min) Pattern Width (mm) Weight (g)
W-71-1G Gravity 1.0 0.29 (3.0) 75 110 120 460
W-71-21G Gravity 1.3 0.29 (3.0) 195 160 165 460
W-71-31G Gravity 1.5 0.29 (3.0) 230 190 185 460
W-71-4G Gravity 1.8 0.29 (3.0) 230 220 220 460
W-71-1S Suction 1.0 0.29 (3.0) 75 95 100 460
W-71-21S Suction 1.3 0.29 (3.0) 195 140 155 460
W-71-31S Suction 1.5 0.29 (3.0) 230 170 170 460
W-71-4S Suction 1.8 0.29 (3.0) 230 195 195 460
W-71-01 Pressure 0.8 0.34 (3.5) 240 200 190 -
W-71-02 Pressure 1.0 0.34 (3.5) 230 300 265 -

FULIAN W-77 Specifications

Model Feed Type Fluid Nozzle Orifice (mm) Air Pressure MPa (bar) Air Consumption (ml/min) Fluid Output (ml/min) Pattern Width (mm) Weight (g)
W-77-1G Gravity 1.5 0.34 (3.5) 290 285 290 530
W-77-21G Gravity 2.0 0.34 (3.5) 340 390 335 530
W-77-31G Gravity 2.5 0.34 (3.5) 350 500 385 530
W-77-4G Gravity 3.0 0.34 (3.5) 360 560 400 530
W-77-1S Suction 1.5 0.34 (3.5) 290 250 260 460
W-77-21S Suction 2.0 0.34 (3.5) 350 360 280 460
W-77-31S Suction 2.5 0.34 (3.5) 400 440 290 460
W-77-4S Suction 3.0 0.34 (3.5) 410 480 320 460
W-77-01 Pressure 1.2 0.34 (3.5) 430 480 380 -

W-71 and W-77 Pneumatic Spray Guns for Latex and Standard PaintsW-71 and W-77 Pneumatic Spray Guns for Latex and Standard PaintsW-71 and W-77 Pneumatic Spray Guns for Latex and Standard PaintsW-71 and W-77 Pneumatic Spray Guns for Latex and Standard PaintsW-71 and W-77 Pneumatic Spray Guns for Latex and Standard PaintsW-71 and W-77 Pneumatic Spray Guns for Latex and Standard PaintsW-71 and W-77 Pneumatic Spray Guns for Latex and Standard PaintsW-71 and W-77 Pneumatic Spray Guns for Latex and Standard Paints

Available configurations.

Source configuration labels are preserved. Confirm the selected option with your inquiry.

Configuration SKU / reference Unit price
W-71 Upgraded Model - Gravity Feed 1.0 Nozzle 597084864609-1 USD 50.20
W-71 Upgraded Model - Gravity Feed 1.3 Nozzle 597084864609-2 USD 50.20
W-71 Upgraded Model - Gravity Feed 1.5 Nozzle 597084864609-3 USD 50.20
W-71 Upgraded Model - Gravity Feed 1.8 Nozzle 597084864609-4 USD 50.20
W-71 Upgraded Model - Suction Feed 1.0 Nozzle 597084864609-5 USD 50.20
W-71 Upgraded Model - Suction Feed 1.3 Nozzle 597084864609-6 USD 50.20
W-71 Upgraded Model - Suction Feed 1.5 Nozzle 597084864609-7 USD 50.20
W-71 Upgraded Model - Suction Feed 1.8 Nozzle 597084864609-8 USD 50.20
W-71 Upgraded Model - Pressure Feed 0.8 Nozzle 597084864609-9 USD 50.20
W-71 Upgraded Model - Pressure Feed 1.0 Nozzle 597084864609-10 USD 50.20
W-77 Upgraded Model - Gravity Feed 2.0 Nozzle 597084864609-11 USD 57.10
W-77 Upgraded Model - Gravity Feed 2.5 Nozzle 597084864609-12 USD 57.10
W-77 Upgraded Model - Gravity Feed 3.0 Nozzle 597084864609-13 USD 57.10
W-77 Upgraded Model - Suction Feed 2.0 Nozzle 597084864609-14 USD 57.10
W-77 Upgraded Model - Suction Feed 2.5 Nozzle 597084864609-15 USD 57.10
W-77 Upgraded Model - Suction Feed 3.0 Nozzle 597084864609-16 USD 57.10
W-77 Upgraded Model - Pressure Feed 1.2 Nozzle 597084864609-17 USD 57.10
